沧州铭意管道专业生产Z系列支座 托座

Z6焊接导向支座构造：

焊接导向支座_Z6焊接导向支座，由支座×1，PTFE（聚四氟乙烯）板×1，滑动底板×1组合而成，主要工艺为弯制和焊接。Z6焊接导向支座和Z5焊接滑动支座主体支座部分相同，导向底板两侧焊有导向立板和加强筋，另外，聚四氟乙烯板的尺寸与焊接滑动支座不同。

Z6焊接导向支座材质：

铭意管道建议≤300°C时，选用材质为Q235B，材料代号S；≤450°C时，选用材质为钢20，材料代号R；≤555°C时，选用材料为12Cr1MoV，材料代号H。

铭意管道Z6焊接导向支座的型号有：Z6.57S，Z6.76S，Z6.89S，Z6.108S，Z6.133S，Z6.159S，Z6.168S，Z6.194S，Z6.219S，Z6.245S，Z6.273S，Z6.298S，Z6.325S，Z6.355S，Z6.377S，Z6.406S，Z6.426S，Z6.457S，Z6.480S，Z6.508S，Z6.530S，Z6.558S，Z6.630S，Z6.720S，Z6.820S，Z6.920S，Z6.1020S，Z6.1120S，Z6.1220S。

The welding guide bearing, bearing by x 1, PTFE (PTFE) in x 1, x 1 sliding plate combination, the main process for bending and 6 welding and Z5 welding guide bearing sliding bearing main bearing part of the same orientation of both sides of the base plate welded with a vertical guiding plate and stiffeners, the other, PTFE the size of the plate with different welding sliding bearings. Less than or equal to 300 DEG C, the material is Q235B, material code S; less than 450 DEG C, the material is 20 steel, material code R; less than or equal to 555 DEG C, the selection of materials for 12Cr1MoV, material code H.
